T Flip-Flop

T Flip-Flop

The T Flip-Flop can take in a short button press and change the output of the gate. (One button press = Powers on until next button press)
AND Gate

AND Gate

The AND Gate powers the output only if both input signals are on
XOR Gate

XOR Gate

The XOR gate only powers the output if there is one powered input and unlike the OR gate won't power it if both inputs are powered
NOT Gate

NOT Gate

The NOT gate inverses the input (On = Off, Off = On)
OR Gate

OR Gate

The OR gate powers the output only if one or both inputs are powered
